Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 231

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 231
853. APPLICATION OF TRACESPRINGS for trucks and heavy wag-ons. Saves the shoulders of horsesfrom fatigue and abrasion. … 854. SERPOLLETS STEAMTRICYCLE. —A, coil boiler; B,coal bunker; C, water tank. Thecoal shute enters thefurnace and feeds thelire automatically.Water is fed to thegenerator directlyfrom an adjustablepump stroke. SeeNos. 199, 200, 201. NAVIGATION AND ROADS. 221

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
