Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 232

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 232
855. STEAM FIREENGINE. Vertical tubu-lar boiler. Vertical steampump, with yoke connec-tion to fly-wheel crank. Gould pattern. … 856. JACKETLESS GASOLINE CARRIAGEMOTOR, with two cylinders inline on two cranks at oppositepoints. Four-cycle type. Explo-sion in cylinders simultaneously,reducing vibration. Cylindercooled by air circulation over theradial ribs.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
