Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 232

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 232
856. JACKETLESS GASOLINE CARRIAGEMOTOR, with two cylinders inline on two cranks at oppositepoints. Four-cycle type. Explo-sion in cylinders simultaneously,reducing vibration. Cylindercooled by air circulation over theradial ribs. … 857. GASOLINE MOTORCARRIAGE.—Two full seatsand single seat for driver. Themiddle seat turns over to getat the motor and gear. 858. LIGHT ELECTRICCARRIAGE, with singleseat. The motor is attachedto the frame and gearedto a speed shaft, and bysprocket and chain to thewheel axle. 222 NAVIGATION AND…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
