Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 234

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 234
862. BABY-CARRIER TRICYCLE.—An extension of the driving axle of anordinary bicycle, with a supplementarywheel to balance and for safety, so thata convenient vehicle is made for carryingchildren or packages NAVIGATION AND ROADS. 223 … 863. ELECTRIC TRICYCLE, Bar-row pattern. The single forward wheel isswivelled to the vehicle frame for steeringand is also the driving wheel. It has a spurwheel on the inside of the rim in which theelectric-motor pinion meshes. The motorswings with the steering-wheel frame, and isconnected to the…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
