Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 252

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 252
a pinion, andD, the driven wheel. The three pinions are connectedwith pivoted arms; then the swinging of the spurwheel B around its eccentric axis will give a variablemotion to the wheel D. 951. VARIABLE RECIPROCATINGMOTION from a rotating spiral spursector meshed in racks inclined to theline of… … 242 GEARING. 952. IRREGULAR CIRCULAR MOTIONfrom an elliptically eccentric gear train. C is theelliptic driving wheel turning with the shaft at D.B is the intermediate gear with a pinion follower tothe eccentric gear C. A and B are attached by anarm pivoted on their respective shafts, so that Brises…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
