Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 259

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 259
e opposite or reverse wheel, and vice versa. 982. ECCENTRIC GEAR.—Irregularinverse motion from elliptic speed gear.The balanced arm T is fixed to the crankshaft and turns with it. The gear A is el-liptical, as is also the gear a. Gear A isfixed to the frame with one of its centrescoincident with… … 983. SUN AND PLANET CRANK MOTION,used by James Watt on the steam engine. Gear, centres are held by connecting arm. B is fixed toconnecting rod_. ind does not revolve on its owncentre, but moves around the axis of the fly-wheelA with a slightly oscillating motion. The wheel A revolves twice onits…
