Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 271

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 271
n sliding in the slot makes a quick qN return of the bell crank and connecting rod. 1031. IRREGULAR ROCKING MOTION in an arm having an endless groove of any re-quired shape, with the radius of the longitudinalaxis equal to the radius of the pin. Pin notshown. 1032. ROCKING ARM by cam groove.A… … 1034. TRIANGULAR CURVED ECCENTRIC, which by its peculiar form makes a stop motion ateach half-revolution of the cam, for any portion of thestroke, according to the length of the concentric portionof the cam. 1035. TRIANGULAR ECCENTRIC forproducing a stop motion at each half-revolutionof the face…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
