1228. LOG CONVEYOR.—A Hnk chainwith hooks running in a trough. 1229. ROPE TRAMWAY, over-head system. Elevation, showingthe switch rails for transferring thecarrier bucket around the terminal tothe return rope. Loading or unload-ing of the bucket is done at thetransfer switch. 1230. Plan showing the… … 1231. AUTOMATIC DUMP-ING CAR.—The floor of thecar slopes upward to the centreat an angle that will allow thematerial to slide out. A chockat any point desired for dump-ing trips the holding-lever andreleases both side doors at once. TOGGLE JOINT, for a stone breaker. 1233. STONE CRUSHER. —Thepower…
