Dingey, Peter Spear. [from old catalog] · New York, J. Wiley & sons · leaf 101
this 58 PATTERN MAKING. flange and step, it must revolve with the sweep; to dothis, the set screws, E and F, must be tightened, the pin-plate, B, taken off the sweep, and the set screw, //, loos-ened ; this will allow the spindle to revolve in its tapersocket in the ordinary way. For drums over 6… … i:^ 01^ I PAJ TE RN MA KIA G. 5 9 MAKING WINDING DRUMS FROM PATTERNS. METHOD OF CUTTING THE GROOVE. Fig. 114 shows a section of a Grooved Winding Drumabout 3 ft. diameter, and Fig. 115 shows the way pat-tern may be constructed. Z> is a 4x4 stick; on it three discs, A, B, C, arefastened and…
Patternmaking
