1246. CENTRIFUGAL SEPARATOR.— A central revolving shaft carries a set of conicalperforated plates, between which perforatedplates are fixed to the shell of the machine.Grain or other material is fed at the top, andan air blast at the bottom. Centrifugal actiondischarges the material at the… … passing the chutes 1247 rt!. Front end view. 1247. MAGNETIC ORE SEP-ARATOR, Buchanan type. Twocylinders, magnetized by powerfulhorseshoe electro-magnets, are re-volved at considerable speed. Thepulverized ore is fed from hopperson top of the rolls ; the iron is held r — to the rolls and thrown off…
