Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 325

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 325
265. ADJUSTABLE POST HANGER. 1266. ADJUSTABLE FLOOR STAND, shaft bearing. 1267. CONTINUOUS TRAVERSINGROLLER or ball bearing for an axle. 1268. ROLLER WHEEL ANTI-FRICTIONBEARING. 1269. BALL BEARINGS in an adjustable journal box. Aloosesleeve is inserted betweenthe balls and the shaftto prevent wear… … 1270. Longitudinal section. MILL AND FACTORY APPLIANCES. 315
