Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 387
1556. LAPIDARY OR LITHOLOGICALLATHE for amateur work. A vertical spindlewith disc lap of lead, driven by a bevel gear andcranks, through a vertical shaft pulley and belt.A splitting disc and spindle are also driven fromthe main pulley. 1557. WIRE-DRAWING MACHINK a, the reel. /^, draw plate. r,… … 1558. WIR&COVERING MACHINE.—The wire is passed through a hollow re-volving spindle a, having a small longitu-dinal motion from a vibrating cam to lapthe threads. The face plate revolving withthe spindle carries two or more spools, <r, <r,with guide eyes, d, d^ vibrating with thespindle.…
Mechanical movements
