Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 411

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 411
of 26degrees when of the following pro-portions : 2 % ^^P T W4 c --f D=E F= 1661. OIL SWITCH MOVEMENT WITH THREELEVERS AND TWO LINKS.—Levers A, H, and iV are con-nected to links D and / and frame M. ^ is a lever with a handlepivoted to frame Q, at B, and connected to link D at C. Link D, connected… … STRAIGHT LINE MOVEMENTS. 401 connected to lever N at L, and is also connected to moving frameM at K, which frame M carries contacts on extensions at P, P, P.Lever A^, connected to link / at L, is pivoted to frame Q at 0.This movement gives a straight line motion to the frame M.W is a wall upon…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
