Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 62

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 62
151. CORRUGATED TUBE-PRESSURE GAUGE.—The pressure within the tube expands it on the cor-rugated side and through the link connections withthe index hand moves the hand. MEASUREMENT OF POWER. 51 … 152. RECORDING PRESSUREGAUGE, Edson model. D. corrugal-ed diaphragm bearing thepressure; G, connecting rod from dia-phragm to crank-pin, on the shaft on whichthe index hand is fixed, as also the armand pencil bar, H^, H^, in front of therecord sheet; K, K, winding barrels forthe record sheet driven…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
