Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 267

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 267
1034. TRIANGULAR CURVED ECCENTRIC,which by its peculiar form makes a stop motion ateach half-revolution of the cam, for any portion of thestroke, according to the length of the concentric portionof the cam. 1035. TRIANGULAR ECCENTRIC for producing a stop motion at each half-revolutionof the face…

Mechanical movements
