52. CORLISS VALVE GEAR.—Operated by asingle eccentric througha lever and connectingrods. Steam and exhaustvalves are worked by pinson a rocking wrist plate.The trips on the steam-valve gears are controlled by the governor. 253. LOCOMOTIVE LINK-MOTIONVALVE GEAR.—In thisarrangement the slottedlink is… … 254
