Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 107

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 107
cts as a piston.Steam is admitted to thischamber by means of a by-pass. The tendency wouldbe to force out the piston,and so draw the ends of thepipe closer together, but asthe steam in the pipe and in the chamber is of the same total pressure,each force neutralizes the other, and the joint is…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
