Mechanical movements, powers, devices and appliances (1901)
Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley & company · leaf 258
eful, but illustrating thechanged conditions of gear motion. Gears a and/i are fixed to the crank shaft. Gears g and /are fixed to a hollow shaft turning on the shaftn m. Gears ^, /; are fixed on a hollow shaft andturn on shaft n m. The arm /^ / is fast on andsupported by shaft n m. Gears e^ d are…
Mechanical movements
