1175. WATCH REGULATOR.—The outer end of the balance spring is fixed to a stud atR, and the inner end to the balance wheelarbor. The index hand carries two curb pinsat P, between which the spring vibrates, form-ing a neutral point in its length which limitsthe arc of movement of the balance wheel,… … 1176. ANTIQUE WATCH ESCAPE-MENT.—A pinion on the balance-wheel arbormeshes in a crown gear, on the shaft of whicha mutilated screw of large pitch releases theteeth of the escapement and gives an impulseby the incline of the screw. 19 •90 HOROLOGICAL.
