Mechanical movements, powers, devices and appliances (1901)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley & company · leaf 353

An illustration from Mechanical movements, powers, devices and appliances, 1901, leaf 353 — 1433. STEAM COTTON PRESS, forrepressing and condensing baled cotton.The geared sectors, driven by the double-rack piston rod and piston, increase thepressure immensely at the latter part of thestroke by the toggle-joint action of the con-necting rods as they approach the radialbearing of the… … 1434. TOGGLE-BAR PRESS.—The rota-tion of the disc a by the lever handle bringsthe toggle bars to a vertical position, with in-creasing pressure upon the platen. The tog-gle bars have spherical ends fitted to sphericalcups in the top and bottom discs. <ii Inr

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
