Mechanical movements, powers, devices and appliances (1901)
Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley & company · leaf 49
pulleypivoted central to the curves on the face of thediscs. 40 TRANSMISSION OF POWER. ii6. TRANSMISSION OF CIRCULAR MOTIONby right-angled cranks on each shaft. The pair of crankconnections carry the right-angled cranks over the centre.The principle of the locomotive wheel connections. 117. THREE…
Mechanical movements
