Mechanical movements, powers, devices and appliances (1901)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley & company · leaf 86

An illustration from Mechanical movements, powers, devices and appliances, 1901, leaf 86 — 263. VARIABLE EXPANSION GEAR,with one eccentric. The movement of tliefulcrmn of the eccentric bar lever by thescrew changes the throw of the valve. … 264. SINGLE ECCENTRIC VARIABLEVALVE THROW.— Fink link gear for aD valve. The link block is moved in thecurved slot of the link for variation of valvethrow, adjustable by the hand-wheel.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
