Mechanical movements, powers, devices and appliances; (1903)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 147
497. WATER WHEEL GOVERNOR.—The wheelmotion drives the bevel gear at a and the hollow spindle,b, revolving the balls and connecting arms. The smallcentral spindle has a vertical motion, due to the centrif-ugal force of the balls. The central spindle carries a pinwhich slides in a slot in the outer… … 498. IMPACT WATER WHEEL, Leffel pat-tern. Step buckets. Efficiency, eighty-five per cent.
Mechanical movements
