An illustration from Mechanical movements, powers, devices and appliances;, 1903, leaf 170 — NK, Miller model. In this form thesiphon is inverted, holding the water seal tobalance the water head in the tank in theuptake of the siphon. The cap over the= long end of the siphon is to seal the air inthe siphon until the sewage pressure isequal to the water-balanced leg. 604. AUTOMATIC FLUSH… … 605. ATOMIZER.—A small streamrunning down an incline is atomized atthe nozzle by a blast of air.
