Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 149

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 149
144 AIR-POWER MOTORS AND APPLIANCES. 354. PNEUMATIC MOISTENING APPARATUS. Com-pressed air is supplied to the atomizing nozzles at various points in a … factor} by the main pipe A. The water is supplied by the smallerpipe below to the water nozzles, and is atomized and vaporized incontact with the air from the nozzles together with the induced airdrawn in by the jets. The wings guide the vapor toward the ceiling,and also collect the excess of water…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
