649. AIR COMPRES-SOR CYLINDER, PIS-g^. TON AND VALVES.— Pattern of the Ingersoll,Sergeant Drill Co. Takesits air through a hollow pis-ton rod at E to the interiorof the piston^ The annular valves, G, G, open and close by theirmomentum. H, H, discharge valves closed by springs; J, J, waterjacket.… … ^S,/-. AIR POWER APPLIANCES. 175
