Mechanical movements, powers, devices and appliances; (1903)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 185
657. CRANK EQUALIZING AN-GLE in air compression. Used toequalize the mean pressure of thesteam and air pistons. The cylindersare set at an angle of 45 . Waringand Rand system. … : KTATc^ suBPir 658. DIRECT AIR PRESSUREPUMP.—Two chambers for alternatingthe pumping action are placed near thewater surface in a well or other watersupply. The chambers have suction andforce valves. A four-way switch cocknear the air pump alternates the flow ofcompressed air to and from the…
Mechanical movements
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
