Steam power plant auxiliaries and accessories; (1922)
Croft, Terrell, 1880- ed, Dufflin, Daniel John, 1911- ed · New York, [etc] McGraw-Hill book company, Inc · leaf 304
(P, Fig. 287)is to produce and maintain a vacuum in the condenser byremoving the air which enters with the exhaust steam. Theair may leak into the exhaust system in various ways, asthrough imperfectly-packed pipe-joints and stuffing-boxes.Also, it may pass into theboilers with the feedwater,and… … ILb. Or 135 Cu. Ft. Of Steam-l2*JoPressure Difference^ 126 Lb. Or About 2Cuff. Of Water Circulating? Pump-: Fig. 287.—Diagram Of Elementary JetCondenser Showing Relative Volumes AndPressures Of Air, Water And Steam. (Onthe basis of one pound of steam.) Explanation. — Imagine aclosed vessel to…
Steam power plants · Pumping machinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
