Mechanical movements, powers, devices and appliances; (1903)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 189

An illustration from Mechanical movements, powers, devices and appliances;, 1903, leaf 189 — - stop on the piston rod,which automatically stops the lift at any set point by closing the air valve. DUPLEX PXEUMATIC RIVETER. — The striking piston, A, is en-cased in a strikine: cvlinder. Cso that the tool, T, receives ablow alternately from the ham-mer piston. A, and from thecylinder, C, on… … AIR POWER APPLIANCES. l8l

Mechanical movements
