Mechanical movements, powers, devices and appliances; (1903)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 198

An illustration from Mechanical movements, powers, devices and appliances;, 1903, leaf 198 — 702. MECHANICAL FLYER. — Asmall windmill with two or four blades,when quickly revolved by the string andforked spindles makes a pretty illustrationof a flying machine. Section IX ELECTRIC POWER AND CONSTRUCTION, Generators, Motors, Wiring, Controlling and Measuring, Lighting^Electric Furnaces,… … 703. SERIES WOUND MOTOROR GENERATOR.—A motor if thecurrent is supplied through the wires Pand N, and a generator if the armatureis rotated, when the current can be takenfrom the wires P and N

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
