Mechanical movements, powers, devices and appliances; (1903)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 200
714. FOUR-POLE COM.POUND GENERATOR, show-ing shunt winding and rheostatconnection. Wiring is successiveon each pole in the oppositedirection for both shunt andcurrent. … 715. ELECTRIC GENERATOR CONSTRUC-TION.—Compound winding, in which a winding oftlie field magnets is in shunt with the armature, anda second winding of the field magnets.is m series ordirect connection with the outer circuit. The shuntwinding should be small wire. S, Shunt connected with armature…
Mechanical movements
