An illustration from Mechanical movements, powers, devices and appliances;, 1903, leaf 257 — 248 GEARING. … AUTOMATIC CLUTCH ^[OTIOXFOR REVERSING.—The bevel wheels B, C arethe drivers in contran- di-rection; D is a doubleclutch on the shaft feather.The revolution of the pinon hevA wheel E moves the weighted ball F through the action ofthe bell-crank lever and connecting rod until the ball is past the…
