Mechanical movements, powers, devices and appliances; (1903)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 366
DECK BRIDGE TRUSSES.i486. Single strut deck truss for shortspans, 30 to 40 feet 1487. Double strut deck trussfor 50 to 70 feet span, 1488. Multi^pie strut decktruss for 100feet span. 1489. BRIDGE TRUSS.-^Inclined strut and tie rod for eachpanel,with stiff compression upperchord. Vertical members…
Mechanical movements
