Mechanical movements, powers, devices and appliances; (1903)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 69
i88. ^THORXYCROFTBOILER.—A large steel drum above and a waterdrum below, connected with a large num-ber of bent tubes. The water return isthrough a large tube at the rear end ofthe boiler. … 189. SEE WATER TUBE BOILER.—A series of short straight tubes connecting a hori-zontal steam drum with a rectangular water baseon each side of the furnace. Return tube at backof boiler. STEAM POWER. 61
Mechanical movements
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
