Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 101

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 101
extension fitting the outer case.A revolving lunette controlled by gearon main shaft allows the lip to pass; acontinuous gear train operates thevalve. 341. Exterior with valve gears. 94 STEAM POWER. 342. HOLLY ROTARY ENGINE.— The two geared pistons mesh their longteeth into the recesses of the…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
