Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 109

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 109
371^. THE STERLINGBOILER.—The hot gases ofcombustion pass lengthwisethrough the three stacks oftubes guided by the fire brickpartitions. All the fire sur-face divided by 12 equals theboiler horse power. Tubesare cleaned by steam blowpipes. Circulating pipes out-side the setting. … Z7ih. THE WORTHING-TON WATER TUBEBOILER.—The water tubesections are between headersand cross each other in series;the lower ends of the diagonalsections are connected with across pipe for circulation fromthe steam drum. Has theAmerican stoker attached.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
