Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 124

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 124
421/. FLEXIBLE METALLIC TUB-ING.—The corrugations are deep indentedrings spun or pressed from a plain tube.It may be also made spiral. Section VI. MOTIVE POWER. Gas and Gasoline Engines, Valve Geaf and Appliances, Connecting Rods and Heads. … 422. GASOLINE ENGINE, Olds model. Plan showinglocation of valve chest and valve gear, operated from an eccentric withan alternating sector gear for an impulse at every other revolution.
