Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)
Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 131
443. GOVERNOR AND VARIABLE CAM for a gas engine. The centrifugal movement of the governor balls slides the sleeve on the governor shaft, and also the variable cam -^ sleeve, ^, on the driving shaft, by the bell-crank VV lever, e. The disc roller, ^, on an arm of a rock ^-^ shaft, rolls upon one or… … 444. INLET VALVE for gas engine.A valve disc slightly held in contact withthe seat by the spring. Air holes should bedrilled close together around the valve seat,so that combined air area shall be largerthan the area of the gas inlet.
