Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 160

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 160
566. HYDRAULIC INTENSIFIER. — High pressure obtained from low pressure by differentialpistons. A, Low-pressure cylinder; D, high-pressurecylinder and plunger. … 566 a. PORTABLE HYDRAULIC RIVETER.—An inverted hydraulic ram is operated bythe small pump and lever attached to the topof the ram. The return stroke is made bythe small reverse ram at the rear of the driv-ing ram.
