Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 165

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 165
589. UNIVERSAL PIPE JOINT.—The flanges^ are faced at 45° to the line of the pipe, with athrough bolt at right angles to the faces of the flanges.The joint may be made at any angle up to 90®. ^^^^^^^^^^^^^ ^^^^^^ ^^^zz^zs^ ^^^^^^^^s^\^.^^^^^s^^ SI 590. TOGGLE CLIP PIPE JOINT.—AJ quick connecting… … 591. BIBB, with crank-moved valve open-ing against the pressure.
