Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 197

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 197
706. ELECTRIC GENERATOR CONSTRUCTION.—Shunt winding, in which the field winding is in parallelwith the armature winding and connected with the circuitat the brush holders. A, Armature; C, commutator; hand h\ brushes ; a, c, field connections ; S, field winding. 190 ELECTRIC POWER AND CONSTRUCTION.… … 708. RING ARMATURE.—Method of continuouswinding and sectionalconnections with thecommutator. The dot-ted lines are the circuitconnection with thebrushes.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
