Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 198

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 198
713. BIPOLAR SHUNT GEN-ERATOR, showing the shunt wind-ing on both fields and its connectionto the brushes, with interveningrheostat controller. … 714. FOUR-POLE COM-POUND GENERATOR, show-ing shunt winding and rheostatconnection. Wiring is successiveon each pole in the oppositedirection for both shunt andcurrent.

Mechanical movements
