Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 213

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 213
765. TWO-MASTED OR DIPPING LUG. —The sails are square, except at the top, wherethey are bent to yards hanging obliquely to th«masts. 4, foresail; 5, mainsail. … 766. NEWPORT CAT-BOAT.—Sail bentto mast and extended by boom and gaff, witha fore-stay to a short bowsprit. 5, mainsail. 767. SLOOP.—A mainsail and jib withfore- and back-stays. 2, jib; 5, mainsail.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
