Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 226

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 226
845. Section through reflector and level. NAVIGATION AND ROADS. 219 … 846. ROAD MACHINE,for scraping and levellingcommon roads. 847. REVERSIBLE ROADROLLER.—The tongue is at-tached to the frame that carriesthe drivers seat, and is bal-anced by the weight on therear arm. By unlocking thecatch the horses wheel aroundthe roller with the tongue andseat frame, and the…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
