Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 227

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 227
853. APPLICATION OF TRACESPRINGS for trucks and heavy wag-ons. Saves the shoulders of horsesfrom fatigue and abrasion. … 854. SERPOLLETS STEAMTRICYCLE. —A, coil boiler; B,coal bunker; C, water tank. Thecoal shute enters thefurnace and feeds thefire automatically.Water is fed to thegenerator directlyfrom an adjustablepump stroke. SeeNos. 199, 200, 201. NAVIGATION AND ROADS. 22]

Mechanical movements
