Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 257

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 257
the fixed gear A. Thesmall gear S reverses the mo-^tion of the gear F, to shaft ofwhich the arm T is fixed. Thearm T moves backward, carry-ing the pinion S around thebevel gear A, which is fixed to the arm T, giving the bevel wheel F aforward motion, or in the same direction as the arm T. 991.…

Mechanical movements
