Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 266

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 266
1029. STOP MOTION from a wrist or cranlpin. The relative amount of stop and motiordepends upon the diameter of crank-pin circleand length of the connecting-rod slot, plus thediameter of crank pin. Used in brick machines. 1030. VARIABLE RECIPROCATING MOTIONfrom the circular motion of a wrist pin on…

Mechanical movements
