Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 275

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 275
1079. EQUALIZING LEVERS ORTOES, for variable rod movement. 1080. VARIABLE CRANK MOTION.—An eccentric slot in a stationary face plate guides aslide block and wrist pin in a slotted crank. Con-necting rod drives the cutter bar of a shaping-machine. … 1081. SPIRAL-GROOVED FACE PLATE, for feed motion. Obsolete ; but useful for irregu-lar motion, in which the spiral grooves may bewavy or zigzag. 1082. LEVER, guided by a volute face plate.

Mechanical movements
