Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 277

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 277
1092. CAM-OPERATED SHEARS.-Many modifications of this device are in use. … •S^?? 310 1093. IRREGULAR CAM MOTION to valverods. An irregular cam, acting between frictionrollers in a yoke frame. Positive irregular rectili-near motion. An old steam-engine valve gear.

Mechanical movements
