Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 292

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 292
HOROLOGICAL. 285 1155. RECOIL ESCAPEMENT. — In thisform the forward face of the teeth of the escape-ment A leans forward from the radial lines. Thefront face of each pallet is in line with the frontface of the teeth, so that the extreme part of thependulum stroke gives a recoil movement to…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
